Stainless Steel A286 Fasteners

A286 Fasteners, Material Overview & Form Factors

A286 is a high-performance alloy used wherever standard fasteners cannot meet the corrosion, temperature, or strength envelope. TorqBolt manufactures the full A286 fastener range, bolts, nuts, screws, washers, studs, and custom forgings, under one ISO 9001:2015 quality system, with PED 2014/68/EU module-H qualification for pressure-equipment service.

Where A286 Excels

A286 is specified in oil & gas wellhead components, refinery heat exchangers, petrochemical reactors, power-generation turbines, marine offshore platforms, and pharmaceutical / food-grade processing. ASTM A453 Grade 660 covers it for high-temperature bolting of pressure vessel and valve flanges, with expansion coefficients comparable to austenitic stainless steels.

Form Factors Available

Standards & Certification

A286 fasteners are supplied with EN 10204 3.1 (validated by the manufacturer’s inspection representative independent of manufacturing) or 3.2 (also validated by the purchaser’s inspector or the inspector designated by official regulations) material test reports as standard. Additional certification packages: NACE MR0175 / ISO 15156, NORSOK M-650, API 6A (wellhead), PED 2014/68/EU. Third-party inspection by TUV, Lloyd's, BV, DNV, SGS, and Intertek arrangeable on order.

: specification facts on this page checked against ASTM A453/A453M, ISO 15156-3, ASME B16.5, AMS 5737, ASME B18.2.3.6M, ASME B18.2.4.6M, ASTM A193/A193M, ASTM A320/A320M, ASTM A540/A540M, EN 10204, API 20E.

A286, Iron-Nickel-Chromium Superalloy

A-286 (UNS S66286, ASTM A453 Grade 660) is a precipitation-hardened austenitic stainless steel for high-temperature bolting, with expansion coefficients comparable to austenitic stainless steels. Chemistry per ASTM A453 Table 3: 24.0–27.0% Ni, 13.5–16.0% Cr, 1.00–1.50% Mo, 1.90–2.35% Ti, 0.35% Al max, 0.10–0.50% V and 0.001–0.010% B.

ASTM A453 covers it for bolts, screws, nuts and studs for pressure vessel and valve flanges in high-temperature service. Class A is solution treated at 900°C (1650°F) for 2 h min, Class B at 980°C (1800°F) for 1 h min, both liquid quenched, then aged at 720°C (1325°F) for 16 hours and air cooled. Classes A, B and C require 895 MPa min tensile, 585 MPa min yield and 15% min elongation.

A-286 fasteners ship per ASTM A453 grade 660 (classes A/B/C/D) and AMS 5737 with EN 10204 3.1 / 3.2 certification. Classes A, B and C are stress-rupture tested at 650°C (1200°F) when the design temperature is above 427°C (800°F); Class D does not require it and is stamped NR. ISO 15156-3 Table A.26 accepts UNS S66286 for sour service at 35 HRC max in the solution-annealed and aged or solution-annealed and double-aged condition, up to 65°C and 100 kPa H2S partial pressure.
